Applications
- Gas-phase filtration
- Offices
- Hospitals
- Airports
Highlights
- Remove volatile organic compounds (VOC’s)
- Odors
- Compact design
- Simple installation and handling
Technical Specifications
| Media: | AC between sythetic layer | Type: | High efficiency, activated carbon | |
| Frame: | Polystyrene (PS) | Media Weight: | 400gsm | |
| Max. Operating Temperature: | 50°C | Gasket: | Without |
Order Code
| Filter Type | Filter Class | Dimensions (mm) | Gasket |
|---|---|---|---|
| AFV : Activated Carbon V-Compact Filter | 4: G4 7: F7 | 592x592x292 | W: Without P: Continuous Pu Foam E: EPDM Flat |
| Filter Model | Filter Class (EN 779) | Dimensions WxHxD (mm) | Filtration Area (m²) | Nominal Airflow (m³/h) | Pressure Drop (Pa) |
|---|---|---|---|---|---|
| AFV-4-287-592-292-W | G4 | 287x592x292 | 4,5 | 1700 | 70 |
| AFV-4-402-592-292-W | G4 | 402x592x292 | 6 | 2310 | 70 |
| AFV-4-490-592-292-W | G4 | 490x592x292 | 7,4 | 2820 | 70 |
| AFV-4-592-592-292-W | G4 | 592x592x292 | 9 | 3400 | 70 |
| AFV-7-287-592-292-W | F7 | 287x592x292 | 4,5 | 1700 | 100 |
| AFV-7-402-592-292-W | F7 | 402x592x292 | 6 | 2310 | 100 |
| AFV-7-490-592-292-W | F7 | 490x592x292 | 7,4 | 2820 | 100 |
| AFV-7-592-592-292-W | F7 | 592x592x292 | 9 | 3400 | 100 |
