Applications
- Dust collection systems
- Gas turbine air intake systems
- Power plants
- Compressors
- Pharmaceutical and food industries
- Welding applications
Highlights
- High filtration area
- Rubber or PU foam gasket to ensure airtight sealing
- Suitable for jet pulse cleaning (optional)
- Strong construction
- Equal spacing between each pleat enable air flow to pass through the filter media
Technical Specifications
| Filter Class: | M5 - F9 | Inner Diameter: | 240 mm | |
| Media: | Cellulose + Synthetic, Nano Coated | Outer Diameter: | 420 mm | |
| Frame: | Galvanized Steel | Max. Operating Temperature: | 80 °C |
Order Code
| Filter Type | Filter Class |
Inner Diameter |
Outer Diameter |
Lenght (mm) |
Faceguard | Gasket |
|---|---|---|---|---|---|---|
| FCY : Cylindrical Filter | M5 F9 |
240 mm | 420 mm | 500 660 1000 |
FW: Without | W: Without |
| Filter Model | EN 779 (cancelled) |
ISO 16890 | Dimensions WxHxD (mm) |
Filtration Area (m²) |
Filter Media |
Nominal Airflow (m³/h) |
Initial Pressure Drop (Pa) |
|---|---|---|---|---|---|---|---|
| FCY-CB-Ø420-240x500 | M5 | Coarse 90% | 420x240x500 | 15 | Cellulose + Synthetic | 625 | 100 |
| FCY-CB-Ø420-240x660 | M5 | Coarse 90% | 420x240x660 | 20 | Cellulose + Synthetic | 830 | 100 |
| FCY-CB-Ø420-240x1000 | M5 | Coarse 90% | 420x240x1000 | 30 | Cellulose + Synthetic | 1250 | 100 |
| FCY-CN-Ø420-240x500 | F9 | ePM1 80% | 420x240x500 | 15 | Nano Coated | 625 | 250 |
| FCY-CN-Ø420-240x660 | F9 | ePM1 80% | 420x240x660 | 20 | Nano Coated | 830 | 250 |
| FCY-CN-Ø420-240x1000 | F9 | ePM1 80% | 420x240x1000 | 30 | Nano Coated | 1250 | 250 |
“Other dimensions are available on request.”
