Applications

  • Pre-filter for ventilation equipment and HVAC
  • Basic ventilation systems

Highlights

  • Fire resistant (M1 / F1)

Technical Specifications

Filter Standard:ISO 16890Rec. Final Pressure Drop EN13053:Initial ΔP +50 Pa or initial ΔP x3
whichever is lower
Filter Class:ISO CoarseMax. Operating Tempature: 80˚C
Media:Synthetic FiberThickness:10 - 15 - 20 - 25- 30 mm

Order Code

Filter TypeFilter
Class
Media Weight
(g/m)
Thickness (mm)Width (mm)Length (mm)
GR : Synthetic
Roll Filter
G2
G3
G4
M5
100
150
200
250
300
T10
T15
T20
T25
T30
1000-200010.000-20.000
Filter ModelEN 779
(cancelled)
IS016890Media
Material
Dimensions
WxL
(mm)
Thickness
(mm)
Media Weight
(g/m²)
GR-G2-100-T10-1000-20000G2Coarse 25%Synthetic1.000x20.00010100
GR-G2-100-T10-2000-20000G2Coarse 25%Synthetic2.000x20.00010100
GR-G3-150-T15-1000-20000G3Coarse 45%Synthetic1.000x20.00015150
GR-G3-150-T15-2000-20000G3Coarse 45%Synthetic2.000x20.00015150
GR-G4-200-T20-1000-20000G4Coarse 55%Synthetic1.000x20.00020200
GR-G4-200-T20-2000-20000G4Coarse 55%Synthetic2.000x20.00020200
GR-M5-300-T30-1000-20000M5Coarse 80%Synthetic1.000x20.00030300
GR-M5-300-T30-2000-20000M5Coarse 80%Synthetic2.000x20.00030300
