Applications
- Pharmaceutical and biotechnology industries
- Life science
Highlights
- Compact construction
- Suitability for limited space
- Customizable cover design on request
- Flexibility any dimensions
Technical Specifications
| Filter Standard: | EN 1822 and ISO 29463 | Rec. Final Pressure Drop: | Initial pressure drop x2, (max. 600 Pa) |
|
| Filter Class: | H13 - H14 | Max. Operating Temperature: | 80˚C | |
| Media: | Glass fiber | Inner Diameter: | 80 - 108 - 110 mm | |
| Frame: | Galvanized Steel | Outer Diameter: | 150 - 175 - 230 mm |
Order Code
| Filter Type | Filter Class | Inner Diameter | Outer Diameter | Lenght (mm) | Faceguard | Gasket |
|---|---|---|---|---|---|---|
| HCY : HEPA Cylindrical Filter | H13 H14 | 80 mm 108 mm 110 mm | 150 mm 175 mm 230 mm | Available for request | FW: Without FC: Faceguard inner side FB: Facegaurd on Both side | W: Without P: Continuous Pu Foam PP: Pu Foam on Both Side E: EPDM Flat EE: EPDM Flat on Both Side |
“Any inner, outer and lenght dimensions are available on request.”
