Applications

  • Final filter for cleanrooms
  • Pre-filter for HEPA filters

Highlights

  • High quality filtration
  • Low initial pressure drop
  • Disposable
  • Suitable for HEPA Boxes and Cabinets

Technical Specifications

Filter Standard:EN 1822 and ISO 29463Max. Operating Tempature:80˚C
Filter Class:E10 - E11 - E12Faceguard:Aluminium sheet (powder coated)
Media:High quality glass fiberGasket: EPDM flat, EPDM flat continous
and PU foam
Frame:MDFSealing Compound:Two component polyurethane
Rec. Final Pressure Drop:Initial pressure drop x2,
(max. 600 Pa)
Seperator: Hotmelt

Order Code

Filter TypeFilter
Class
FramePleat HeightDimensions
(mm)
FaceguardGasket
EC : EPA Ceiling Filter
MDF Frame
E10
E11
E12
M: MDF1: 50 mm
2: 65 mm
3: 75 mm
4: 85 mm
5: 90 mm
6: 100 mm
7: 125 mm
610x610x78FW: Without
FC: On Clean Side
FD: On Dirty Side
FB: On Both Sides
W: Without
P: Continuous Pu Foam
PP: Pu Foam on Both Side
E: EPDM Flat
EE: EPDM Flat on Both Side
C: Continuous Grey EPDM
CC: Grey EPDM on Both Side
U: U Gasket

EPA CEILING FILTER (MDF FRAME) - EC 78

Filter ModelEN 1822ISO 29463Dimensions
WxHxD
(mm)
Filtration
Area
(m²)
Pleat
Height
(mm)
Nominal
Airflow
(m³/h)
Initial
Pressure Drop
(Pa)
EC-E10-M-1-305-305-78-FC-PE10-305x305x782,35015080
EC-E10-M-1-305-610-78-FC-PE10-305x610x784,55030080
EC-E10-M-1-457-457-78-FC-PE10-457x457x7855034080
EC-E10-M-1-610-610-78-FC-PE10-610x610x7895060080
EC-E10-M-1-610-915-78-FC-PE10-610x915x7813,55090080
EC-E10-M-1-610-1220-78-FC-PE10-610x1220x781850120080
EC-E11-M-1-305-305-78-FC-PE11ISO 15 E305x305x782,35015090
EC-E11-M-1-305-610-78-FC-PE11ISO 15 E305x610x784,55030090
EC-E11-M-1-457-457-78-FC-PE11ISO 15 E457x457x7855034090
EC-E11-M-1-610-610-78-FC-PE11ISO 15 E610x610x7895060090
EC-E11-M-1-610-915-78-FC-PE11ISO 15 E610x915x7813,55090090
EC-E11-M-1-610-1220-78-FC-PE11ISO 15 E610x1220x781850120090
EC-E12-M-1-305-305-78-FC-PE12ISO 25 E305x305x782,35015095
EC-E12-M-1-305-610-78-FC-PE12ISO 25 E305x610x784,55030095
EC-E12-M-1-457-457-78-FC-PE12ISO 25 E457x457x785,15034095
EC-E12-M-1-610-610-78-FC-PE12ISO 25 E610x610x7895060095
EC-E12-M-1-610-915-78-FC-PE12ISO 25 E610x915x7813,55090095
EC-E12-M-1-610-1220-78-FC-PE12ISO 25 E610x1220x781850120095

“Other dimensions are available on request.”
“Differential Pressure Tolerance ±10%”

EPA CEILING TYPE FILTER (MDF FRAME) - EC 150

Filter ModelEN 1822ISO 29463Dimensions
WxHxD
(mm)
Filtration
Area
(m²)
Pleat
Height
(mm)
Nominal
Airflow
(m³/h)
Initial
Pressure Drop
(Pa)
EC-E10-M-7-305-305-150-FC-PE10-305x305x1504,512515035
EC-E10-M-7-305-610-150-FC-PE10-305x610x150912530035
EC-E10-M-7-610-610-150-FC-PE10-610x610x1501812560035
EC-E10-M-7-610-1220-150-FC-PE10-610x1220x15036125120035
EC-E11-M-7-305-305-150-FC-PE11ISO 15 E305x305x1504,512515045
EC-E11-M-7-305-610-150-FC-PE11ISO 15 E305x610x150912530045
EC-E11-M-7-610-610-150-FC-PE11ISO 15 E610x610x1501812560045
EC-E11-M-7-610-1220-150-FC-PE11ISO 15 E610x1220x15036125120045
EC-E12-M-7-305-305-150-FC-PE12ISO 25 E305x305x1504,512515060
EC-E12-M-7-305-610-150-FC-PE12ISO 25 E305x610x150912530060
EC-E12-M-7-610-610-150-FC-PE12ISO 25 E610x610x1501812560060
EC-E12-M-7-610-1220-150-FC-PE12ISO 25 E610x1220x15036125120060

“Other dimensions are available on request.”
“Differential Pressure Tolerance ±10%”
