Applications
- Pre-filter for ventilation equipment and HVAC
- Paint booths
Highlights
- High dust holding capacity
- Dust / paint holder
Technical Specifications
| Filter Standard: | ISO 16890 | Frame: | Cardboard | |
| Filter Class: | ISO Coarse | Rec. Final Pressure Drop EN13053: | Initial ΔP +50 Pa or initial ΔP x3 whichever is lower |
|
| Media: | Glass Fiber | Max. Operating Temperature: | 80 °C |
Order Code
| Filter Type | Filter Class |
Frame | Dimensions (mm) |
|---|---|---|---|
| GC : Glass Fiber Panel Filter |
G3 G4 |
C: Cardboard | 592x592x48 |
| Filter Model | EN 779 (cancelled) |
ISO 16890 | Media Material |
Dimensions WxHxD (mm) |
Nominal Airflow (m³/h) |
Initial Pressure Drop (Pa) |
|---|---|---|---|---|---|---|
| GC-G3-C-287-592-48 | G3 | Coarse 45% | Glass Fiber | 287x592x48 | 1700 | 55 |
| GC-G3-C-592-592-48 | G3 | Coarse 45% | Glass Fiber | 592x592x48 | 3400 | 55 |
| GC-G4-C-287-592-96 | G4 | Coarse 55% | Glass Fiber | 287x592x96 | 1700 | 70 |
| GC-G4-C-592-592-96 | G4 | Coarse 55% | Glass Fiber | 592x592x96 | 3400 | 70 |
“Differential Pressure Tolerance ( ±10% + 5 Pa ) or ( 10 Pa + 5 Pa ) whichever is greater”
