Applications
- Microelectronics
- Laboratories
- Life science
- Healthcare
- Food and Beverage Industry
Highlights
- Filter seal-leak test (DIN 1946-4 and ISO 14644-3)
- Test ports for pressure drop, test groove (on request) and aerosol injection
- Available air flow adjustment damper fitted to the spigot (on request)
- Available in various construction and dimensions
- Simplified maintenance and disinfection
- Easily removable air outlets
- Available powder coated or stainless steel
- Central, corner, side fixing for diffuser
- Duct connection type: Top, Side, Z (Lower ceiling heights)
- Powder coated in any RAL Code
Order Code
| ULPATEK CODE | Width mm (Box Dimension) |
Length mm (Box Dimension) |
Height* mm (Box Dimension) |
Width mm (HEPA Filter Dimension) |
Length mm (HEPA Filter Dimension) |
Height mm (HEPA Filter Dimension) |
Width mm (Diffuser Dimension) |
Length mm (Diffuser Dimension) |
|---|---|---|---|---|---|---|---|---|
| HFB-SS-X-F-W-C-610-610-78-M | 627 | 627 | 400 | 610 | 610 | 78 | 650 | 650 |
| HFB-SS-X-F-W-C-610-610-150-M | 627 | 627 | 400 | 610 | 610 | 150 | 650 | 650 |
| HFB-SS-Y-K-W-C-610-610-80-M | 627 | 627 | 400 | 610 | 610 | 80 | 650 | 650 |
| HFB-SS-Y-K-W-C-610-610-128-M | 627 | 627 | 400 | 610 | 610 | 128 | 650 | 650 |
| HFB-SS-Z-T-W-C-610-610-69-M | 627 | 627 | 400 | 610 | 610 | 69 | 650 | 650 |
| HFB-SS-X-F-D-M-610-610-150-M (tool free) |
627 | 627 | 400 | 610 | 610 | 150 | 650 | 650 |
| Filter Type | Flange | Spigot Side | Leakproof Gasket Surface |
Damper | Diffuser Connection |
Dimensions (mm) |
Spigot Diameter |
|---|---|---|---|---|---|---|---|
| HFB : HEPA Filter Box |
P: Powder Coated SS: Stainless Steel 304 SS316: Stainless Steel 316 |
X: Top Inlet Y: Side Inlet Z: Z Inlet |
F: Flat Surface T: Test Groove K: Knife Edge |
D: Exist W: Without |
C: Center S: Corner M: Magnet |
610x610x78 | A: 125 B: 150 C: 160 D: 200 M: 250 F: 300 L: 315 X: 355 Z: 0 |
*Height will be changed according to design.
