Applications
- Final filter for HVAC or cleanrooms
- Suitable for duct applications
Highlights
- V-shaped design
- Individiual test certificate (acc. to EN 1822 - ISO 29463)
- Simple and light weight
Technical Specifications
| Filter Standard: | EN 1822 and ISO 29463 | Max. Operating Tempature: | 80˚C | |
| Filter Class: | E10 - E11 - E12 - H13 - H14 | Model: | V (Vertical), H (Horizontal) | |
| Media: | High quality glass fiber | Sealing Compound: | Two component polyurethane | |
| Frame: | Aluminium, Galvanized & Stainless Steel |
Seperators: | Hotmelt | |
| Rec. Final Pressure Drop: | Initial pressure drop x2, (max. 600 Pa) |
Order Code
| Filter Type | Filter Class | Frame | Design | Dimensions (mm) |
|---|---|---|---|---|
| HD : Efficient Duct Type Filter |
E10 E11 E12 H13 H14 |
A: Aluminium G: Galvanized Metal SS: Stainless Steel 304 SS316: Stainless Steel 316 |
V: Vertical H: Horizontal |
202x600x87 600x202x65 |
| Filter Model | EN 1822 | ISO 29463 | Dimensions WxHxD (mm) |
Filtration Area (m²) |
Nominal Airflow (m³/h) |
Initial Pressure Drop (Pa) |
|---|---|---|---|---|---|---|
| HD-E10-G-V-202-600-87 | E10 | - | 202x600x87 | 2,6 | 200 | 140 |
| HD-E10-G-H-600-202-65 | E10 | - | 600x202x65 | 2,6 | 200 | 140 |
| HD-E11-G-V-202-600-87 | E11 | ISO 15 E | 202x600x87 | 2,6 | 200 | 160 |
| HD-E11-G-H-600-202-65 | E11 | ISO 15 E | 600x202x65 | 2,6 | 200 | 160 |
| HD-E12-G-V-202-600-87 | E12 | ISO 25 E | 202x600x87 | 2,6 | 200 | 180 |
| HD-E12-G-H-600-202-65 | E12 | ISO 25 E | 600x202x65 | 2,6 | 200 | 180 |
| HD-H13-G-V-202-600-87 | H13 | ISO 35 H | 202x600x87 | 2,6 | 200 | 180 |
| HD-H13-G-H-600-202-65 | H13 | ISO 35 H | 600x202x65 | 2,6 | 200 | 180 |
| HD-H14-G-V-202-600-87 | H14 | ISO 45 H | 202x600x87 | 2,6 | 200 | 200 |
| HD-H14-G-H-600-202-65 | H14 | ISO 45 H | 600x202x65 | 2,6 | 200 | 200 |
“Differential Pressure Tolerance ±10%”
